| Fitting position | front axle |
| Height (mm) | 49.7 |
| Supplementary article/info 2 | with bolts/screws |
| Outer diameter (mm) | 340 |
| Bolt hole circle Ø (mm) | 112 |
| Quantity required | 2 |
| Num. of holes | 5 |
| Wheel bolt bore Ø (mm) | 15.3 |
| Machining | high-carbon |
| Brake disc thickness (mm) | 30 |
| Surface | zink flake coated |
| Centering diameter (mm) | 65 |
| Min. thickness (mm) | 27 |
| Brake disc type | vented |
| Quality | premium |
| Manufacturer | Productnumber |
| audi | 1K0 615 301 AD , 1K0615301AD |
| audi | 5Q0 615 301 G , 5Q0615301G |
| audi | 8S0 615 301 , 8S0615301 |
| audi | 8S0 615 301 D , 8S0615301D |
| seat | 1K0 615 301 AD , 1K0615301AD |
| seat | 5Q0 615 301 G , 5Q0615301G |
| skoda | 1K0 615 301 AD , 1K0615301AD |
| skoda | 5Q0 615 301 G , 5Q0615301G |
| skoda | JZW 698 302 DG , JZW698302DG |
| vw | 1K0 615 301 AD , 1K0615301AD |
| vw | 5Q0 615 301 G , 5Q0615301G |
| vw | 5QN 615 301 A , 5QN615301A |
| vw | JZW 698 302 DG , JZW698302DG |
| Usage numbers |
| MBD1528PD |
| A.B.S. 18194 |
| APEC DSK2867 |
| APEC SDK6675 |
| ATE 24.0130-0225.1 |
| BENDIX 562663BC |
| BLUE PRINT ADV184372 |
| BORG & BECK BBD5963S |
| BOSCH 0 986 479 734 |
| BREMBO 09.C306.11 |
| BREMBO 09.C306.1X |
| COMLINE ADC1498V |
| COMLINE AND6838 |
| DELPHI BG9109 |
| DELPHI BG9109C |
| DELPHI BG9202C |
| FEBI BILSTEIN 39129 |
| FERODO DDF2000C |
| FERODO DDF2000C-1 |
| FTE BS7706 |
| FTE BS7706B |
| GIRLING 6061335 |
| HELLA 8DD 355 117-201 |
| HELLA PAGID 55298PRO |
| HELLA PAGID 55298PRO_HC |
| HELLA PAGID 55298PRO_HC_B |
| HELLA PAGID 8DD 355 117-201 |
| HELLA PAGID 8DD 355 121-921 |
| HELLA PAGID 8DD 355 129-241 |
| JAPANPARTS DI-0907 |
| JAPANPARTS DI-0907C |
| JURID 562663JC |
| JURID 562663JC-1 |
| LPR V2010V |
| LPR V2010VR |
| METELLI 23-1243C |
| Meyle PD 115 521 0008/PD |
| Meyle PD MBD0171PD |
| MINTEX MDC2253 |
| NK 2047141 |
| NK 3147141 |
| OPTIMAL BS-8712 |
| OPTIMAL BS-8712C |
| OPTIMAL BS-8712HC |
| PAGID 55298PRO |
| REMSA 61485.10 |
| ROADHOUSE 61485.10 |
| sbs 18152047141 |
| SWAG 30 93 9129 |
| TEXTAR 92229803 |
| TEXTAR 92229805 |
| TRUCKTEC AUTOMOTIVE 07.35.258 |
| TRUSTING DF1456 |
| TRW DF6133S |
| VAICO V10-80119 |
| VALEO 197677 |
| ZIMMERMANN 600.3243.20 |
| ZIMMERMANN 600.3243.52 |
| Manufacturer | Model | Version | Engine code | Construction type | Construction start | Construction end | Pk | Power kw |
 audi |
||||||||
 cupra |
||||||||
 seat |
||||||||
 skoda |
||||||||
 vw |
All our standard discs are priced individually, but due to the safety critical aspect of the braking system, Brake Discs must now be purchased in pairs where required and we will add a quantity of 2 to your basket. (Some high-performance discs are sold as a set of two). Our brake pads are sold as a front set or rear set, so purchasing one box will be enough for two discs
See the diameter on the right side of the product image .The best way to ensure you get the correct brake discs is to check the diameter of the brake discs already fitted.
Simply enter your vehicle registration or VIN on our website. Our built-in system will automatically show you the correct brake discs for your car. You can also message us if you need help.
On average, brake discs last between 30,000–70,000 miles, but this varies based on driving style and conditions. Look out for signs like vibrations, noise, or visible wear.
All our brake discs are brand new and meet or exceed OEM standards.
