Fitting position	Front
Thread size 1	m14x1,5 a
Thread size 2	m14x1,5 a
Axle joint length (mm)	315
Svhc	no svhc present!

Product number: 840 0006 10

FAG Front Inner Tie Rod For Toyota Carina Corolla

Out of stock

Price incl. vat.

£ 12,09

Notify me when back in stock

Description

FAG Inner Tie Rod (Rack End)

Genuine FAG inner tie rod engineered to OE specifications for precise steering control and accurate toe adjustment. Connects the steering rack to the outer joint, providing smooth, durable articulation.

What’s Included

Sold individually (one side). For both sides, order quantity 2.

Please check the product photos for the exact contents supplied (e.g., lock washer, boot clamps). If unsure, contact us with your VIN/registration and we’ll confirm.

Key Features

OE-matched thread, length and seat for direct fit
High-strength ball joint with precision bearing surface
Sealed, maintenance-free design with robust dust protection
Corrosion-resistant finish for long service life
Engineered by FAG (Schaeffler), trusted OE supplier

Check Before You Buy

Thread direction: left-hand or right-hand (must match your outer joint/adjuster)
Overall length & adjuster style to maintain alignment range
Rack boot (gaiter) compatibility and clamp type
Verify by VIN/registration and FAG/OE part numbers for guaranteed fit

When to Replace

Steering play, knock/clunk over bumps, vague on-centre feel
Feathered or uneven tyre wear (toe in/out issues)
Torn boot, corrosion or grease leakage at the inner joint
MOT/inspection advisory or fail for joint wear/excess movement

Installation Summary

Record current toe or count turns before removal to preserve approximate length
Use the correct inner tie-rod tool; fit new lock washer where specified
Ensure the rack boot is intact and properly clamped; replace if torn
Complete a professional wheel alignment after installation

Warranty: FAG steering components are covered by the manufacturer’s warranty when supplied via authorised distributors. Correct installation and alignment are required for warranty validity.

Manufacturer	Productnumber
toyota	45503-19036 , 4550319036
toyota	45503-19125 , 4550319125
toyota	45503-19135 , 4550319135
toyota	4550319036
toyota	4550319125
toyota	4550319135

Usage numbers
BLUE PRINT ADT38763
DELPHI TA1632
FEBI BILSTEIN 43276
LEMFÖRDER 11914 02
LEMFÖRDER 1191402
MEYLE 30-16 030 0071
MEYLE 30160300071
MONROE L13102
MOOG TO-AX-2976
MOOG TO-AX-2977
MOOG TOAX2976
MOOG TOAX2977
RUVILLE 916908
SCHAEFFLER GRUPPE 840 0006 10
SCHAEFFLER GRUPPE 840000610
SIDEM 45837
TRW JAR188

Manufacturer	Model	Version	Engine code	Construction type	Construction start	Construction end	Pk	Power kw
toyota
