    Schaeffler INA
    Width 1 (mm) 17
    Number of teeth 1 108
    Svhc no svhc present!
    Product number: 530 0016 10

    Ina Timing Belt Kit For Citroën Citroën (Df-psa) Dacia Peugeot 106 205 206 306 3

    Price excl. vat.
    £ 27,82

    Description


    INA Engine Drive Solutions

    Timing Belt Kit

    The INA Timing Belt Kit contains all the components needed for a precise, reliable camshaft drive. Each kit is engineered to OE specifications for maximum durability, performance, and peace of mind.

    OE-grade quality Complete solution Long service life
    INA Timing Belt Kit main view
    INA Timing Belt Kit beauty shot INA timing belt close-up INA timing belt kit with water pump

    Kit Features

    • Complete package: includes timing belt, tensioner, idlers, and all required hardware.
    • OE specification: precise tooth profile and belt length for correct timing.
    • High durability: reinforced belt fibres, premium bearings, and wear-resistant pulleys.
    • Optional water pump kits: available for full cooling system refresh during belt replacement.

    When to Replace

    • Follow manufacturer’s schedule (commonly 60,000–100,000 miles or 5–7 years).
    • Signs of belt wear such as cracks, fraying, or missing teeth.
    • Noise from tensioner or idlers.
    • Coolant leak from the water pump if integrated.
    Tip: Replace the belt, tensioner, idlers, and water pump together to avoid repeat labour and ensure reliability.

    How to Fit (Universal Guide)

    1. Preparation: Engine cold, battery disconnected. Refer to the service manual for timing marks and torque specs.
    2. Remove covers & drain coolant (if water pump is included).
    3. Release belt tension and remove the old belt, tensioner, idlers, and pump if fitted.
    4. Install new components: Fit tensioner/idlers and water pump (if applicable) using new bolts/gaskets, torque to spec.
    5. Fit new belt: Align all timing marks exactly before tensioning.
    6. Reassemble & test: Rotate engine by hand two turns, check marks, start engine, and inspect for leaks/noise.

    Always follow the exact procedure and torque values in your vehicle’s workshop manual.

    Manufacturer Productnumber
    citroËn 00 000 829 19 , 0000082919
    citroËn 00 000 829 54 , 0000082954
    citroËn 0000082919
    citroËn 0000082954
    citroËn 0816.37 , 081637
    citroËn 0816.44 , 081644
    citroËn 0816.45 , 081645
    citroËn 081637
    citroËn 081644
    citroËn 081645
    citroËn 0820.53 , 082053
    citroËn 082053
    citroËn 0829.19 , 082919
    citroËn 0829.29 , 082929
    citroËn 0829.54 , 082954
    citroËn 082919
    citroËn 082929
    citroËn 082954
    citroËn 0831.03 , 083103
    citroËn 0831.14 , 083114
    citroËn 0831.Q4 , 0831Q4
    citroËn 083103
    citroËn 083114
    citroËn 0831Q4
    citroËn 96 033 798 , 96033798
    citroËn 96 097 062 , 96097062
    citroËn 96 281 179 , 96281179
    citroËn 96 403 239 80 , 9640323980
    citroËn 96033798
    citroËn 96097062
    citroËn 96281179
    citroËn 9640323980
    citroËn 97 522 886 , 97522886
    citroËn 97 522 929 , 97522929
    citroËn 97 535 002 , 97535002
    citroËn 97522886
    citroËn 97522929
    citroËn 97535002
    peugeot 00 000 829 19 , 0000082919
    peugeot 00 000 829 54 , 0000082954
    peugeot 0000082919
    peugeot 0000082954
    peugeot 0816.37 , 081637
    peugeot 0816.44 , 081644
    peugeot 0816.45 , 081645
    peugeot 081637
    peugeot 081644
    peugeot 081645
    peugeot 0820.53 , 082053
    peugeot 082053
    peugeot 0829.19 , 082919
    peugeot 0829.29 , 082929
    peugeot 0829.54 , 082954
    peugeot 082919
    peugeot 082929
    peugeot 082954
    peugeot 0831.03 , 083103
    peugeot 0831.14 , 083114
    peugeot 0831.Q4 , 0831Q4
    peugeot 083103
    peugeot 083114
    peugeot 0831Q4
    peugeot 96 033 798 , 96033798
    peugeot 96 097 062 , 96097062
    peugeot 96 281 179 , 96281179
    peugeot 96 403 239 80 , 9640323980
    peugeot 96033798
    peugeot 96097062
    peugeot 96281179
    peugeot 9640323980
    peugeot 97 522 886 , 97522886
    peugeot 97 522 929 , 97522929
    peugeot 97 535 002 , 97535002
    peugeot 97522886
    peugeot 97522929
    peugeot 97535002
    citroËn (df-psa) 0829.54 , 082954
    citroËn (df-psa) 082954
    Usage numbers
    AJUSA 0831.03
    AJUSA 0831.14
    AJUSA 083103
    AJUSA 083114
    BOSCH 1 987 946 578
    BOSCH 1 987 948 930
    BOSCH 1987946578
    BOSCH 1987948930
    CONTINENTAL CTAM CT607K1
    DAYCO KTB 102
    DAYCO KTB102
    DAYCO-AU KTB102E
    FEBI BILSTEIN 11242
    GATES K 015175 XS
    GATES K+15175XS-1
    GATES K+15175XS-2
    GATES K015175XS
    GATES K15175XS1
    GATES K15175XS2
    HK RS1132
    HUTCHINSON KH03
    IPD 20-1132
    IPD 201132
    QUINTON HAZELL QBK104
    QUINTON HAZELL QBK124
    RUVILLE 5660072
    SCHAEFFLER GRUPPE 530 0016 10
    SCHAEFFLER GRUPPE 530001610
    SKF VKMA 03110
    SKF VKMA03110
    SNR KD459.03
    SNR KD45903
    VAICO V42-4172
    VAICO V424172
    Manufacturer Model Version Engine code Construction type Construction start Construction end Pk Power kw
    citroËn citroËn
    peugeot peugeot
